Chemistry Analyzer

Supply, delivery, installation and commissioning of open system Chemistry analyzer according to the following specifications:

The unit should be suitable for a provincial general hospital laboratory and capable of measuring;

·       Specific proteins

·       Electrolytes

·       Enzymes

·       Substrates

·       Drug of abuse

The unit should be automatic, with microprocessor-controlled analyzer, Digital display, and in-built printer with option for external print out devices

Performance characteristics;

·       Test menu : At least 120 selections

·       Test per hour: 200-300 photometric tests.

·       On- board parameters : At least 50

Analyzer system :

·       Random access, Discrete, Automatic, Selectable

·       STAT sample priority.

·       Programming : User defined and calculations

Sample processing

·       Sample tray capacity : 60 to 80 samples

·       Sample Volume : 2- 50 ml

·       Sample dilution : Automatic, Pre and post dilutions

·       Sample identification : Bar code reader (variety of bar code systems)

·       Sample probe : Probe crash protection, Liquid level Detection and clot detection

·       Probe cleaning : Internal and External

Reagent processing

·       Reagent tray Capacity : about 50

·       Reagent storage : Refrigerated compartment

·       Reagent probe : Probe crash protection, Liquid level Detection

·       Probe cleaning : Internal and External

ISE Module

·       Tests : Sodium, Potassium, chloride and lithium

Optical Characteristics

·       Light source : Halogen- Tungsten lamp, easily replaceable

·       Wavelength : 340- 750 nm (approximately)

·       Sensitivity : About 0.0001 OD

Data Processor

·       Operating system : Compatible with Windows XP or VISTA

·       Interface : RS-232 and or USB

·       Memory : > 10GB

·       Data input : key pads, soft touch

·       Display: Digital display.

·       Printer : In built with provision of external printer

·       Control and Calibration: Automatic, can be adjusted through the software: Display of running status, alerts: Diagnosis of working status. : Software should be upgradeable

Physical characteristics

·         Bench top

·         Robust construction and easy to clean

Safety features: Complies with ISO 9001, IEC 601, CE or other: internationally recognized standards.

Spare part and accessories : Manufacturer recommended set of spare parts and accessories – 1 set

Reagents : Complete set up reagents and accessories and additional reagents adequate to operate the system for at least two months

Line voltage : Single Phase, 240 V, 50Hz including suitable UPS

Ambient temperature : 10 C to 40 C

Relative humidity : 40% to 90%

Commissioning

·       Testing and commissioning of the machine to the satisfaction of the user departments.
