Echocardiogram

Description of Function

·       Color Doppler Echocardiography System studying the anatomical abnormalities and blood flow in the heart and associated vessels.

 Operational Requirements

·       Latest generation Electronic Phased array Color Doppler system with Minimum 512 Electronic independent channels.

·       System should be DICOM ready and capable of being interfaced with HIS/RIS/PACS.

·       Should be field up gradable to next generation system on site.

·       2.3 Frequency compounding or better technology for   better resolution and penetration.

Technical Specifications

·       Latest generation Electronic Phased array Color Doppler system with Minimum 512 Electronic independent channels.

·       256 gray shades for sharp contrast resolutions

·       Adult & Pediatric Trans thoracic Cardiac, TEE (Adult & Pediatric)

·       Harmonic Imaging- System should have following modes in harmonic with separate setting for:

·       Tissue Harmonic.

·       Contrast Harmonic

·       Harmonic Angio.

·       Quantification of harmonics imaging

·       Harmonic imaging capability in Adult Cardiac, Pediatric Cardiac and linear Probe

 ·       Gain control in two dimensions for additional level of flexibility to image quality control.

·       Real time high frequency 2D for higher resolution and low frequency Doppler for higher sensitivity in all probes

·       Frame rate should be 300 FPS or more

·       Steerable PW/CW in all Phased Array probes.

·       High-definition acoustic zoom for enlarging sections of 2D and Color flow images with more acoustic information for greater clarity and detail while maintaining an optimal frame rate.

·       Modes – 3D, 2D, M-Mode, Steerable PW/CW Doppler, Color Doppler, and High Definition Color flow.

·       Monitor should be 15" or more, high-resolution color Monitor.

·       Tilt and Swivel monitor should be able to view in all angles and all light conditions.

·       Color Flow Imaging for

·       Increased lateral & spatial resolution.

·       Detection of even subtle areas of turbulence, displaying a more physiological blood flow appearance without loss of frame rate.

·       Color flow with capability of automatically picking up color flow as a function of focal depth

·       Tissue Colorization (B-Color) for improved contrast resolution

·       Application software for Adult, Pediatric, Fetal and Peripheral Vascular and Trans esophageal applications. (All application package should be built into the system)

·       High Frame rate review for better clarity of playback images study in slow motion.

·       Quad loop with memory for pre and post image comparison of any procedure.

·       Memory-256 frames or more in quad loop. M

·       Mode & Doppler Scroll Memory-40 seconds or more

·       Frame grabber facility for post analysis.

·       Various maps for pre and post processing.

·       ECG and respiration trigger facility.

·       User defined system and application presets for multi-user department.

·       Minimum 4.8 GB optical disc drive for image storage and retrieval. (Standard with system)

·       3.21Dedicated integrated dynamic stress echo package for flexible user defined protocols with stacked sub loops facility and contrast stress protocol usable for stress echocardiography.

·       Tissue movement colorization with quantification possibility for IHD/CAD/Heart Failure patients.

·       Three or more transducer ports.

·       Color Map resolution up to 128 levels.

·       Facility for high definition digital acquisition, review and editing of complete patient studies.

·       Facility of Real time perfusion studies

·       PC based Peripheral system comprising of dedicated computer at least 100 GB storage space (Hard disc) with 1 GB RAM or more with a Microprocessor speed of more than 3.00 GHz, frame grabber incorporated (All Software Inclusive) interfaced with the echocardiography machine with DVD writer and a high quality Color Laser printer.

·       CD/DVD produced should be playable on any system.

·       Color M-Mode

System Configuration Accessories, spares and consumables

·       Color Doppler System with all application packages

·       Quad loop for serial studies with High frame rate review.

·       Harmonic imaging capability in all modes. (Tissue, Contrast, Anglo) Integrated Stress

·       Echo Package Digital Storage and Retrieval - 01

·       Adult Cardiac probe Electronics Phased Array probe - 01

·       Pediatric Cardiac probe Electronics Phased Array probe. - 01

·       Electronics Phased Array Probe for Vascular applications- 01

·       Multi plane TEE Probe for Adult as well as Pediatric echocardiography - 01.

·       DVD/CD Recorder with 100 CDs and 100 DVDs

·       Color Print Paper- 500 sheets

·       ECG Cable – 02

Laser Color Printer – 01
