Electrocardiogram

Multichannel ECG machines

Technical specifications and requirements

REQUIREMENTS

·       Multichannel ECG machine

·       Interpretation for each ECG machine

·       Cart with cable support Arm for each ECG machine

·       Appropriate UPS for each ECG machine

·       Standard accessories for each ECG machine

                     i.            Patient cable for resting ECG

                    ii.            ECG printer paper – 1 packet of 100 sheets

                  iii.            AC power cord

                   iv.            Operational manual

                    v.            Chest bulbs and fish clamps – 1set

·       Additional requirements – Please  quote separately

                     i.     Patient cables – 2 extra for each machine

                    ii.     ECG printer paper – 100 packets extra for each machine

                  iii.     Chest bulbs and fish clamps – 2 additional sets   for each machine

   TECHNICAL SPECIFICATIONS

·       12 Lead Resting Electrocardiographic machine

·       Backlit LCD display

·       Resting Interpretation algorithm

·       Full alphanumeric keypad

·       Internal storage of at least 60 digital ECG records

·       Connectivity options via serial ports, internal modem, LAN, Wireless LAN etc.

·       Simultaneous acquisition of 12 leads

·       Standard leads acquired 1,2,3,aVR, aVL, aVF, V1,V2,V3,V4,V5,V6

·       Waveform display : Backlit LCD or equivalent, 3 channel lead groups or complete 8-12 channel presentation

·       Input impedance, Input dynamic range, electrode offset tolerance and common  mode

·       Patient leakage current , chassis leakage current to meet or exceed requirements of   ANSI/AAMI ES1

·       Digital sampling rate : 10,000s/sec/channel used for pacemaker spike detection;  1000s/sec/channel used for recording and analysis

·       Resting interpretation algorithm, connectivity options for bidirectional  communication, flash memory storage of ECGs

·       Thermal recorder: Computer controlled dot array or equivalent

·       Thermal writer speeds 5,10, 25, 50 mm/sec

·       Gain settings: 5,10,or 200 mm/mV

·       Report print formats: Standard or Cabrera: 3+1, 3+3, 6, 12 channels

·       Rhythm print format: 3 Channel, 6 channel, or12 channel

Full alphanumeric keyboard

Frequency response: 0.05 Hz to 300 Hz

Filters – Baseline filter, AC Interference filter 50 Hz, Low pass filter 40 Hz or 150 Hz

·       A/D conversion: 20 Bit or equivalent

·       Device classification: Class 1, Type CF defibrillation proof

·       ECG storage: at least 60 ECGs

·       Power 220 – 240 V, 50 Hz
