Visualisation of Streamlines in an Open Channel

Visualisation of Streamlines in an Open Channel

Code: FFM0023

Fundamentals of Fluid Mechanics Engineering Visualisation of Streamlines in an Open Channel.

Learning Objectives / Experiments

- how differently shaped weirs affect the flow
- visualisation of streamlines for flow incident to a

  weir
- visualisation of streamlines when flowing around

  various drag bodies

[1] visualisation of streamlines during incident flow and flow around various weirs and drag bodies
[2] transparent experimental flume
[3] incident flow demonstrated on two weirs
[4] demonstration of flow around four different drag bodies
[5] contrast medium: ink
[6] distributor for contrast medium with seven nozzles
[7] water level in the experimental flume adjustable via sluice gate at the water inlet and weir at the water outlet
